LPV 모델 및 LTV 모델

선형 파라미터 가변 모델 및 선형 시변 모델

선형 파라미터 가변(LPV) 모델과 선형 시변 모델(LTV)을 만들고 조작하며 분석하고 시뮬레이션합니다. 이러한 모델에서는 비선형 시스템을 근사하고 선형 설계 기법을 비선형 모델에 효율적으로 적용할 수 있습니다.

사용 가능한 기능을 통해 다음을 수행할 수 있습니다.

  • 수학 표현식에서 LPV 모델 또는 LTV 모델 생성.

  • 동작 조건 그리드에 대한 선형 결과를 보간하는 LPV 모델 또는 LTV 모델 생성.

  • 시간 응답 시뮬레이션.

  • 가변 모델과 LTI 모델 간에 신호 기반 연결 지정.

  • 파라미터 그리드에 대한 동특성을 샘플링하여 로컬 LTI 근사 구하기.

  • LPV 또는 LTV 모델 이산화 및 리샘플링.

함수

모두 확장

lpvssLinear parameter-varying state-space model (R2023a 이후)
ltvssLinear time-varying state-space model (R2023a 이후)
getTestValueAccess test values for validating data function (R2023a 이후)
setTestValueModify test values for validating data function (R2023a 이후)
findopCompute operating condition from specifications (R2023b 이후)
sample(Not recommended) Sample linear parameter-varying or time-varying dynamics (R2023a 이후)
ssInterpolantBuild gridded LTV or LPV model from state-space data (R2023a 이후)
stepStep response of dynamic system
impulseImpulse response plot of dynamic system; impulse response data
lsimPlot simulated time response of dynamic system to arbitrary inputs; simulated response data
initialSystem response to initial states of state-space model
RespConfigOptions for step or impulse responses (R2023a 이후)
feedback여러 모델의 피드백 연결
connectBlock diagram interconnections of dynamic systems
series두 모델의 직렬 연결
parallel두 모델의 병렬 연결
lftGeneralized feedback interconnection of two models (Redheffer star product)
c2d연속시간 모델을 이산시간 모델로 변환
d2c이산시간 모델을 연속시간 모델로 변환
d2dResample discrete-time model
xperm Reorder states in state-space models
sminrealEliminates structurally disconnected states, delays, and blocks

블록

모두 확장

LPV System선형 파라미터 가변(LPV) 시스템 시뮬레이션
Varying Lowpass Filter변하는 계수를 갖는 버터워스 필터
Varying Notch Filter변하는 계수를 갖는 노치 필터
PID ControllerContinuous-time or discrete-time PID controller
PID Controller (2DOF)Continuous-time or discrete-time two-degree-of-freedom PID controller
Varying Transfer Function변하는 계수를 갖는 전달 함수
Varying State SpaceState-space model with varying matrix values
Varying Observer FormObserver-form state-space model with varying matrix values
Discrete Varying Lowpass변하는 계수를 갖는 이산 버터워스 필터
Discrete Varying NotchDiscrete-time notch filter with varying coefficients
Discrete PID Controller (2DOF)Discrete-time or continuous-time two-degree-of-freedom PID controller
Discrete PID ControllerDiscrete-time or continuous-time PID controller
Discrete Varying Transfer Function변하는 계수를 갖는 이산시간 전달 함수
Discrete Varying State SpaceDiscrete-time state-space model with varying matrix values
Discrete Varying Observer FormDiscrete-time observer-form state-space model with varying matrix values

도움말 항목

LTV 및 LPV 모델 기본 사항

분석 LTV 및 LPV 모델 사용하기

그리딩된 LTV 및 LPV 모델 사용하기
