    Visualize Simulation Data in Simulink

    Visualizing simulation data throughout the modeling process helps you understand, prototype, and tune your models. In Simulink®, you can select from different data visualization tools to suit your needs:

    • Scope block: View connected signals in a separate compact window.
    • Dashboard block library: Build an interactive interface to control and monitor the simulation by using graphical controls and displays.
    • Record block: View and log signals to the workspace or a file.
    • Simulation Data Inspector: Visualize, compare, and analyze data from multiple simulations in one place.
    • Custom MATLAB® visualizations: Log simulation data to MATLAB and use MATLAB figures and charts to create custom visualizations.
    • 3D Visualizations: Connect to Unreal Engine® to simulate and visualize the behavior of your Simulink models in prebuilt or custom 3D scenes.
