시스템 레벨 시뮬레이션
단일 링크 시뮬레이션 또는 다중 노드 네트워크 시뮬레이션을 기술하는 시스템 레벨 설계의 통신 시스템 모델을 개발합니다.
계층 1의 물리 계층(PHY), 계층 2의 데이터 링크 계층(DLL), 계층 3의 네트워크 계층을 포함하여 개방형 시스템 간 상호 연결(OSI) 참조 모델 프로토콜 스택에서 작동하는 시스템을 모델링합니다. DLL은 네트워크 프로토콜 유형을 식별하고 오류 제어를 제공하며 PHY 계층에서 전송에 필요한 데이터 프레임을 조합합니다. DLL의 매체 접근 제어(MAC) 및 논리 링크 제어(LLC) 부계층은 동일한 채널을 공유하는 두 노드 간에 오류 없는 링크를 제공하는 역할을 합니다.
시스템 레벨 시뮬레이션에서 무선 파형을 보내고 받습니다.
PHY 계층 동작 모델을 사용하는 시스템 레벨 시뮬레이션에서 데이터 패킷을 보내고 받습니다.
다양한 데이터 트래픽 모델, 스케줄링 전략 및 PHY 알고리즘을 사용하여 네트워크 성능을 평가합니다.
상호공존, 간섭 및 채널 손상의 영향을 분석합니다.
처리량, 스케줄링 공정성, 블록 오류율(BLER) 및 스펙트럼 효율성 등의 양을 측정합니다.
시각화 기능을 사용하여 네트워크의 성능을 분석합니다.
5G Toolbox, WLAN Toolbox 또는 Bluetooth Toolbox와 함께 네트워크 시뮬레이션 기능을 사용하려면 Communications Toolbox Wireless Network Simulation Library 애드온을 다운로드하여 설치하십시오.
객체
networkTrafficFTP | FTP application traffic pattern generator (R2020b 이후) |
networkTrafficOnOff | On-Off application traffic pattern generator (R2022a 이후) |
networkTrafficVideoConference | Video conference application traffic pattern generator (R2021a 이후) |
networkTrafficVoIP | VoIP application traffic pattern generator (R2020b 이후) |
wirelessNetworkSimulator | Wireless network simulator (R2022b 이후) |
도움말 항목
- Wireless Network Simulator
Learn how the wireless network simulator object works.
- Plug Custom Channel into Wireless Network Simulator
Learn how to plug a custom channel into the wireless network.
- Composition of NR Nodes (5G Toolbox)
Learn about the composition of NR nodes.
- Communication Between gNB and UE Nodes (5G Toolbox)
Learn about the communication flow between the gNB and UE nodes.
- NR Cell Performance Evaluation with MIMO (5G Toolbox)
Model a 5G new radio cell with MIMO antenna configurations and evaluate network performance.
- Estimate Packet Delivery Ratio of LE Broadcast Audio in Residential Scenario (Bluetooth Toolbox)
Estimate packet delivery ratio of Bluetooth LE audio isochronous broadcast streams in a residential scenario.
- Noncollaborative Bluetooth LE Coexistence with WLAN Signal Interference (WLAN Toolbox)
Simulate Bluetooth LE noncollaborative coexistence with WLAN interference.
- Get Started with WLAN System-Level Simulation in MATLAB (WLAN Toolbox)
Create a multinode WLAN system-level simulation consisting of an IEEE® 802.11ax™ access point (AP) and a station (STA) by using WLAN Toolbox™.
- Evaluate the Performance of Scheduler in a Bluetooth BR/EDR Piconet (Bluetooth Toolbox)
Evaluate the performance of the Bluetooth scheduler by implementing multiple applications with different QoS requirements in a use-case scenario of home environment.
