J1939 통신

J1939 프로토콜을 이용한 차량 네트워크 통신

MATLAB^® 또는 Simulink^®를 사용하여 CAN 네트워크를 통해 송신할 J1939 Parameter Group 및 채널을 생성하십시오.

함수

J1939 채널

`canDatabase`	CAN 데이터베이스 파일 핸들 생성
`j1939Channel`	Create J1939 CAN channel
`configBusSpeed`	Configure bit timing of J1939 channel
`start`	Start channel connection to J1939 bus
`stop`	Stop channel connection to J1939 bus
`receive`	Receive parameter groups from J1939 bus
`transmit`	Send parameter groups via channel to J1939 bus
`discard`	Discard available parameter groups on J1939 channel
`filterAllowAll`	Open parameter group filters on J1939 channel
`filterAllowOnly`	Allow only specified parameter groups to pass J1939 channel filter
`filterBlockOnly`	Block only specified parameter groups on J1939 channel filter

J1939 Parameter Group

`canDatabase`	CAN 데이터베이스 파일 핸들 생성
`j1939ParameterGroup`	Create J1939 parameter group
`j1939ParameterGroupImport`	Import J1939 log file
`j1939ParameterGroupTimetable`	Convert CAN messages or J1939 parameter groups into timetable (R2021a 이후)
`j1939SignalTimetable`	Create J1939 signal timetable from J1939 parameter group timetable (R2021a 이후)
`extractAll`	Occurrences of specified J1939 parameter groups
`extractRecent`	Occurrences of most recent J1939 parameter groups
`extractTime`	Occurrences of J1939 parameter groups within time range

속성

모두 확장

채널 및 Parameter Group 객체

j1939.Channel Properties	Properties of the `j1939.Channel` object
j1939.ParameterGroup Properties	Properties of the `j1939.ParameterGroup` object

블록

모두 확장

J1939 통신 블록 라이브러리

J1939 Network Configuration	Define J1939 network configuration name and database file
J1939 Node Configuration	Configure J1939 node with address and network management attributes
J1939 CAN Transport Layer	Transport J1939 messages via CAN
J1939 Transmit	Transmit J1939 message
J1939 Receive	Receive J1939 parameter group messages

도움말 항목

J1939 Interface
J1939 is a high-level protocol built on the CAN bus that provides serial data communication between electronic control units (ECUs) in heavy-duty vehicles.
J1939 Parameter Group Format
The application layer deals with parameter groups (PGs) sent and received over the network.
J1939 Network Management
Each device on a J1939 network has a unique address.
J1939 Transport Protocols
J1939 transport protocol breaks up PGs larger than 8 data bytes and up to 1785 bytes, into multiple packets.
J1939 채널 워크플로
J1939 Parameter Group 송신 및 수신 다이어그램.
MathWorks Virtual Channels
Emulate virtual CAN channels provided with the toolbox.
Supported Block Features
Supported features of blocks in the Vehicle Network Toolbox™ block library.
Timing in Hardware Interface Models
Determine block execution frequency and relate to real-world time.

추천 예제

Get Started with J1939 Parameter Groups in MATLAB

Create and manage J1939 parameter groups using information stored in DBC files. This example uses file J1939.dbc. Creating and using parameter groups this way is recommended when needing to transmit data to a J1939 network.

라이브 스크립트 열기

Get Started with J1939 Communication in MATLAB

Create and use J1939 channels to transmit and receive parameter groups on a J1939 network.

라이브 스크립트 열기

Simulink에서 J1939 통신 시작하기

이 예제는 Simulink®에서 J1939 Parameter Group(PG) 메시지를 송수신하는 방법을 보여줍니다.

라이브 스크립트 열기

Replay J1939 Logged Field Data to a Simulation

Replay J1939 data from a BLF file acquired from a J1939 system in a real-world application, such as a vehicle running in the field.

라이브 스크립트 열기

Decode J1939 Data from MDF Files

Import and decode J1939 data from MDF files in MATLAB® for analysis. The MDF file used in this example was generated from Vector CANoe using the "System Configuration (J1939)" sample. This example also uses the CAN database file, Powertrain_J1939_MDF.dbc, provided with the Vector sample configuration.
