2상 유체 시스템
2상 유체 시스템의 모델링, 제어 및 시뮬레이션을 보여주는 예제를 살펴보십시오.
추천 예제
Cavitation in Two-Phase Fluid
How two-phase fluid components can be used to simulate cavitation. The model is a translational mechanical converter driven by an oscillating pressure source. During the negative portion of the pressure source cycle, the fluid cavitates, reducing the force produced by the converter. As a result, the converter displacement drifts and does not return to the starting position.
Fluid Vaporization in Pipe
Model the vaporization of water to generate steam. Liquid water enters the pipe at 370 K at a rate of 1 kg/s. The pipe is heated to 1000 K, causing the water flowing inside pipe to saturate.
2상 유체 냉장
이 예제에서는 2상 유체 컴포넌트를 사용하여 증기 압축 냉장 사이클을 모델링합니다. 압축기가 R-134a 냉매를 응축기, 팽창 밸브, 증발기로 순환시킵니다. 압축기에서 나오는 고온 가스가 열 전달을 통해 응축기에서 응축되어 환경으로 전달됩니다. 냉매가 팽창 밸브를 통과하면서 압력이 감소합니다. 이 압력 감소는 냉매의 포화 온도를 낮춥니다. 이를 통해 냉매는 냉장실의 열을 흡수하며 증발기에서 끓습니다. 냉매는 이후 압축기로 돌아가 사이클을 반복합니다. 제어기는 압축기를 켜고 끄는 과정을 반복하면서 냉장실의 온도를 원하는 범위 내에서 유지합니다.
랭킨 사이클(증기 터빈)
이 예제에서는 랭킨 사이클을 기반으로 하는 증기 터빈 시스템을 모델링합니다. 이 사이클에는 고압 터빈과 저압 터빈의 응축을 방지하기 위한 과열 기능과 재가열 기능이 각각 포함되어 있습니다. 또한 사이클은 추출된 증기를 밀폐된 급수 히터에 통과시켜 물을 예열하고 사이클 효율성을 향상하는 재생성도 포함합니다.
Transcritical CO2 (R744) Refrigeration Cycle
Models a vapor-compression refrigeration cycle in which the high pressure portion of the cycle operates in the supercritical fluid region. The refrigerant is carbon dioxide (CO2), also called R744 in this application.
