# misdata

Reconstruct missing input and output data

## Syntax

`Datae = misdata(Data)`

Datae = misdata(Data,Model)

Datae = misdata(Data,MaxIterations,Tol)

Datae = misdata(___,Name,Value)

## Description

`Datae = misdata(Data)`

reconstructs missing input and output time-domain
data.

`Data`

contains time-domain data, which can be in the form of a
`timetable`

, a comma-separated pair of
numeric matrices, or a time-domain `iddata`

object.

Missing data samples (both in inputs and in outputs) are expressed as
`NaN`

s. `Datae`

, which is the same form as
`Data`

, contains the reconstructed data set where the missing
data has been replaced by reasonable estimates.

`Datae = misdata(Data,Model)`

specifies a
model used for the reconstruction of missing data. `Model`

is
any linear identified model (`idtf`

, `idproc`

, `idgrey`

, `idpoly`

, `idss`

).
If no suitable model is known, it is estimated in an iterative fashion
using default order state-space models.

`Datae = misdata(Data,MaxIterations,Tol)`

specifies maximum number of
iterations and tolerance. `MaxIterations`

is the maximum number of
iterations carried out (the default is 10). The iterations are terminated when the
difference between two consecutive data estimates differs by less than
`Tol`

%. The default value of `Tol`

is
`1`

.

`Datae = misdata(___,`

uses additional model options specified by one or more name-value arguments. `Name,Value)`

The available arguments consist of:

`InputName`

and`OutputName`

— Input and output channel names. Use these arguments especially when`data`

is a timetable that has more variables than you want to use, or when there. Also use`OutputName`

to identify the output channels when the timetable`data`

contains more than one output variable. Otherwise, the software interprets only the last variable as an output channel.For example, specify the input and output signal variable names using

`Datae = misdata(data,'InputName',["u1","u3"],'OutputName',"y1")`

. You can use this syntax with any of the previous input-argument combinations.`Ts`

and`TimeUnit`

— Sample time and time units. Use these arguments especially when you are`data`

contains numeric matrices, which do not provide sample-time information.

## Examples

## Algorithms

For a given model, the missing data is estimated as parameters so as to minimize the output prediction errors obtained from the reconstructed data. See Section 14.2 in Ljung (1999). Treating missing outputs as parameters is not the best approach from a statistical point of view, but is a good approximation in many cases.

When no model is given, the algorithm alternates between estimating missing data and estimating models, based on the current reconstruction.

## Version History

**Introduced before R2006a**
