Prototype Deep Learning Networks on FPGA
Deep Learning HDL Toolbox™ provides classes to create objects to deploy series deep learning networks to target FPGA and SoC boards. Before deploying deep learning networks onto target FPGA and SoC boards, leverage the methods to estimate the performance and resource utilization of the custom deep learning network. After you deploy the deep learning network, use MATLAB to retrieve the network prediction results from the target FPGA board.
|Retrieve intermediate layer results for deployed deep learning network|
| Retrieve intermediate layers results for |
|Validate SSH connection and deployed bitstream|
|Release the connection to the target device|
|Run inference on deployed network and profile speed of neural network deployed on specified target device|
|Retrieve prediction results for |
|Deploy the specified neural network to the target FPGA board|
|Compile workflow object|
|Retrieve bitstream resource utilization|
- Prototype Deep Learning Networks on FPGA and SoCs Workflow
Accelerate the prototyping, deployment, design verification, and iteration of your custom deep learning network running on a fixed bitstream by using the
- LIBIIO/Ethernet Connection Based Deep Learning Network Deployment
Rapidly deploy deep learning networks to FPGA boards using MATLAB.
- Profile Inference Run
Obtain performance parameters of an inference run performed for a pretrained series network and a specified target FPGA board.
- Multiple Frame Support
Improve the performance of your deployed deep learning network by using the multiple frame support feature.
