propVal = getantipads(pcbobject)
generates an antipads stack based on the number of signal vias and the number of conductive
layers. propVal can be optionally customized and assigned to
SignalViaAntipad.
getantipads returns an antipad stack of size
SignalViaLocations-by- GroundLayer in the
via. The first non-empty shape from obj.SignalViaAntipad is used for
scalar expansion to build the antipad stack.
Version History
Introduced in R2024a
