Fault Outport
Libraries:
Simulink Fault Analyzer /
Fault Port Blocks
Description
Fault Outport blocks link signals from a model of a fault behavior to an external model. You can use these blocks to output signal data to Simulink® and System Composer™ models.
Use these blocks only in Fault Subsystem blocks. Each Fault Subsystem block can contain only one Fault Outport block.
Examples
Ports
Input
Block Characteristics
Data Types |
|
Direct Feedthrough |
|
Multidimensional Signals |
|
Variable-Size Signals |
|
Zero-Crossing Detection |
|
Version History
Introduced in R2023b
