Network Protocols
R2026bSend and receive data using transmission control protocol (TCP), universal datagram protocol (UDP), and hypertext transfer protocol (HTTP) protocols for real-time applications running on host computer.
Blocks
 | UDP Receive | Receive UDP packets over IP network |
 | UDP Send | Send UDP packets over IP network |
 | TCP/IP Receive | Receive data over TCP/IP network from remote host |
 | TCP/IP Send | Send data over TCP/IP network to another remote host |
 | HTTP Client | Send and receive data from HTTP server over URL connection (Since R2023b) |
Topics
- Modularize Installation of Third-Party Packages and Libraries for Raspberry Pi Hardware
This section describes the workflow for downloading the core and optional application-based libraries and packages.
Featured Examples
Transfer Data over TCP/IP Between Raspberry Pi Sense HAT and Android Device
Use MATLAB® commands to send data over TCP/IP from Raspberry Pi® Sense HAT to an Android™ device and also receive RGB color values from the Android device and display the same on the LED matrix of Sense HAT.
Read and Write to ThingSpeak Channel Using Raspberry Pi HTTP Client Block
Use Raspberry Pi® Blockset to read and write data to a field in a ThingSpeak™ channel. In this example, you read data from the GPIO pin of the Raspberry Pi hardware and write it to a field in a ThingSpeak channel.
