Data Synthesis

Simulate radar sensors, generate signals, detections, and tracks, model propagation channels, clutter, target RCS, and micro-Doppler signatures

Simulate radar data at different levels of abstraction–probabilistic or physics-based. For faster simulations, generate probabilistic radar detections and tracks to test tracking and sensor fusion algorithms. For higher fidelity physics-based simulations, model transmitted waveforms that propagate through the environment, reflect off targets, and are received at the radar. Transition from probabilistic models to the physics-based models programmatically. Simulate multipath propagation, clutter, interference, and target echoes. Define targets as simple geometric shapes or complex structures such as a walking pedestrian or a moving bicyclist. Model both active and passive sensors that scan mechanically or electronically in azimuth and elevation. Extract micro-Doppler signatures to classify radar detections and tracks.

Functions

expand all

mergeDetectionsMerge detections into clustered detections (Since R2021b)
radarDataGeneratorGenerate radar detections and tracks (Since R2021a)
radarEmissionEmitted radar signal structure (Since R2021a)
radarEmitterRadar signals and interferences generator (Since R2021a)
objectDetectionReport for single object detection (Since R2021a)
objectTrackSingle object track report (Since R2021a)
trackHistoryLogicConfirm and delete tracks based on recent track history (Since R2021a)
radarTransceiver Monostatic radar transceiver (Since R2021a)
pulseWaveformLibraryCreate library of pulse waveforms (Since R2021a)
rcscylinderRadar cross section of cylinder (Since R2021a)
rcsdiscRadar cross section of flat circular plate (Since R2021a)
rcssphereRadar cross section of sphere (Since R2021a)
rcstrunconeRadar cross section of truncated cone (Since R2021a)
radarChannelFree space propagation and reflection of radar signals (Since R2021a)
backscatterBicyclistBackscatter radar signals from bicyclist (Since R2021a)
backscatterPedestrianBackscatter radar signals from pedestrian (Since R2019a)
barrageJammerBarrage jammer (Since R2021a)
constantGammaClutterSimulate constant gamma clutter (Since R2021a)
gpuConstantGammaClutterSimulate constant-gamma clutter using GPU (Since R2021a)
twoRayChannelTwo-ray propagation channel (Since R2021a)
widebandTwoRayChannelWideband two-ray propagation channel (Since R2021a)
rcsSignatureRadar cross-section pattern (Since R2021a)

Blocks

Backscatter BicyclistBackscatter signals from bicyclist (Since R2021a)
Backscatter PedestrianBackscatter signals from pedestrian (Since R2021a)
Barrage JammerBarrage jammer interference source (Since R2021a)
Constant Gamma ClutterConstant gamma clutter simulation (Since R2021a)
GPU Constant Gamma ClutterConstant gamma clutter simulation using gpu (Since R2021a)
Radar Data GeneratorGenerate radar sensor detections and tracks (Since R2021b)
Detection ConcatenationCombine detection reports from different sensors
Two-Ray ChannelTwo-ray channel environment (Since R2021a)
Wideband Two-Ray ChannelWideband two-ray channel environment (Since R2021a)
Pulse Waveform LibraryLibrary of pulse waveforms (Since R2021a)
