# flatearthpoly

Clip polygon to world limits

## Syntax

`[latf,lonf] = flatearthpoly(lat,lon)`

[latf,lonf] = flatearthpoly(lat,lon,longitudeOrigin)

## Description

`[latf,lonf] = flatearthpoly(lat,lon)`

trims
`NaN`

-separated polygons specified by the latitude and longitude
vectors `lat`

and `lon`

to the limits ```
[-180
180]
```

in longitude and `[-90 90]`

in latitude, inserting
straight segments along the +/- 180-degree meridians and at the poles. Inputs and
outputs are in degrees.

Display functions automatically cut and trim geographic data when required by the map
projection. Use the `flatearthpoly`

function only when performing set
operations on polygons.

`[latf,lonf] = flatearthpoly(lat,lon,longitudeOrigin)`

centers
the longitude limits on the longitude specified by the scalar longitude `longitudeOrigin`

.

## Examples

## Tips

The polygon defined by `lat`

and `lon`

must be well-formed:

The boundaries must not intersect.

The vertices of outer boundaries must be in a clockwise order and the vertices of inner boundaries must be in a counterclockwise order, such that the interior of the polygon is always to the right of the boundary.

For more information, see Create and Display Polygons.

## Version History

**Introduced before R2006a**
