LU Solver
Solve AX = B when A is a square matrix
Libraries:
DSP System Toolbox /
Math Functions /
Matrices and Linear Algebra /
Linear System Solvers
Description
The LU Solver block solves the linear system AX = B by applying LU factorization, where:
A is an MbyM square matrix input through the A port.
B is an MbyN matrix input through the B port.
X is the MbyN output matrix and is the unique solution to the equations.
Ports
Input
Output
Block Characteristics
Data Types

Direct Feedthrough

Multidimensional Signals

VariableSize Signals

ZeroCrossing Detection

Algorithms
The LU algorithm factors a rowpermuted variant (A_{p}) of the square input matrix A as
$${A}_{p}=LU$$
where L is a lower triangular square matrix with unity diagonal elements, and U is an upper triangular square matrix.
The matrix factors are substituted for A_{p} in
$${A}_{p}X={B}_{p}$$
where B_{p} is the rowpermuted variant of B, and the resulting equation
$$LUX={B}_{p}$$
is solved for X by substituting Y = UX, and solving two triangular systems.
$$\begin{array}{l}LY={B}_{p}\hfill \\ UX=Y\hfill \end{array}$$
Extended Capabilities
Version History
Introduced before R2006a
